Drying Shaker
Drying Shaker
1. The excitation intensity is as high as 8g, which can be adjusted according to the working conditions, and can effectively dry the drilling cuttings.2. ···
Telephone：4008636869 mobile phone：+86-15667593754 mailing address：zcgk89116955@126.com
Equipment parameters
1. The excitation intensity is as high as 8g, which can be adjusted according to the working conditions, and can effectively dry the drilling cuttings.
2. Fast cuttings conveying speed and high processing capacity.
3. Screen frame angle adjustment device, adjustment range - 1 ° to + 5 °
4. Plate frame screen, wedge type pressing device, easy to change the screen quickly.
5. Funnel feeding mode design can effectively reduce the feeding height and facilitate the conveyor feeding.
| model | ZCZS/T585G | ZCZS/Z585G |
|---|---|---|
| Vibration track | Ellipsoid | Linear type |
Treatment capacity m3/h | 140 | 130 |
| Motor power KW | 1.94+1 | 2.2×2 |
| Maximum exciting force KN | 60 | 65 |
| Screen area m2 | 585×1165×4 | 585×1165×4 |
| Box angle° | -1～+5 | -1～+5 |
| Theoretical weight Kg | 550 | 1650 |
| Dimensions mm | 2970×1750×1380 | 2970×1750×1380 |
